Discharging Action of Sharp Point: Corona Discharge

by
In the study of electrostatics and electric fields, one interesting phenomenon is the discharging action of sharp points, It is commonly known as corona discharge. This effect is directly related to the distribution of electric charge on conductors and the intensity of the electric field around them.

Discharging Action of Sharp Point: Corona Discharge

It not only explains why sharp objects behave differently from smooth ones in an electric field but also finds numerous applications, from lightning conductors to electrostatic precipitators.

Concept of Electric Field at Sharp Points

When a conductor is charged, the electric charges always reside on its outer surface. The distribution of charge depends strongly on the shape of the conductor.
On smooth and large spherical surfaces, the charge spreads evenly, leading to a relatively uniform electric field.
On the other hand, at regions of sharp curvature (like pointed edges), the charge density becomes very high.
According to electrostatics, the electric field intensity (E) near a conductor is directly proportional to the surface charge density (σ) and inversely proportional to the radius of curvature (r):
E α  σ / r
This means that a smaller radius of curvature (sharper point) results in a very strong electric field in the neighbourhood of that point. If the electric field at the sharp tip exceeds a critical value, it can ionize the surrounding air molecules. This process leads to the phenomenon called corona discharge.

What is Corona Discharge?

Corona discharge is the process of gradual ionization of air (or any surrounding gas) near a sharp point of a charged conductor due to the intense electric field.
When the field strength near the point exceeds the dielectric strength of air (approximately 3 x 106 V/m), nearby air molecules lose electrons and become positively charged ions.
These ions are repelled by the similarly charged conductor, causing a faint luminous glow, hissing sound, or in some cases, a bluish discharge.
Thus, corona discharge acts as a continuous leakage of charge from sharp edges or pointed conductors.

Discharging Action of Sharp Point

The sharp point of a conductor acts as a continuous source of ionization of air. This phenomenon is also referred to as the point discharge.
If the conductor is positively charged, the free electrons from air molecules are attracted towards it, leaving behind positive ions which are repelled outward.
If the conductor is negatively charged, electrons are repelled outward while the heavier positive ions move slowly.
In both cases, there is a movement of charge carriers away from the conductor, which gradually neutralizes or discharges the conductor. This is why sharp objects tend to lose charge faster compared to spherical ones.
This action of sharp points is often summarised as:
 “A sharp point discharges more effectively than a smooth surface.”

Examples of Corona Discharge

Lightning Conductor (or Rod):

A lightning conductor is a long, pointed metal rod fixed at the top of tall buildings. Due to corona discharge, it gradually leaks charge into the atmosphere and reduces the chance of a sudden lightning strike directly hitting the building. Even if lightning occurs, the conductor provides a safe path to ground.
Discharging Action of Sharp Point: Corona Discharge-Atmosphere
Atmosphere

Electrostatic Precipitator:

In industries, corona discharge is used to remove dust and smoke particles from chimneys. A high-voltage sharp wire ionizes the air, charging dust particles which are then attracted to oppositely charged plates.
Discharging Action of Sharp Point: Corona Discharge-Smoke
Smoke

High-Voltage Power Lines:

On very high voltage transmission lines, corona discharge sometimes occurs around conductors, visible as a bluish glow. Though it causes energy loss, it also prevents sudden breakdown of insulation.

Spraying and Painting:

Electrostatic spraying of paints and pesticides makes use of corona discharge, ensuring even distribution of particles.

Natural Corona Discharge (St. Elmo’s Fire):

Sailors often observe a bluish glow at the tips of ship masts during thunderstorms. This is a natural example of corona discharge, historically known as St. Elmo’s fire.

Factors Affecting Corona Discharge

Several factors determine the effectiveness of point discharge:
Sharpness of the Point: Sharper points have stronger electric fields, hence higher discharge rate.
Applied Potential Difference: Greater voltage increases the intensity of the electric field.
Medium Surrounding the Conductor: Corona discharge depends on dielectric strength; for example, air, helium, or nitrogen behave differently.
Humidity and Pressure: High humidity facilitates easier ionization, while higher atmospheric pressure increases dielectric strength, thus requiring higher voltage.

Significance in Physics and Technology

Corona discharge demonstrates how nature maintains electrical equilibrium by gradually neutralizing charges.
It shows the importance of geometry in electrostatics, where the shape of an object strongly influences its electrical behaviour.
In engineering, controlled corona discharge is exploited for purification, spraying, and high-voltage equipment design.
In safety, it plays a vital role in lightning protection systems.

Conclusion

The discharging action of sharp points, or corona discharge, is a attractive manifestation of electrostatics. It illustrates how the distribution of charge and the strength of the electric field are intimately connected with the geometry of a conductor.
The strong electric field near sharp tips ionizes the surrounding air, leading to leakage of charge in the form of corona discharge. This principle not only explains natural phenomena like lightning and St. Elmo’s fire but also has important practical applications in industry, technology, and safety systems.
The discharging action of sharp point refers to the phenomenon where a sharp or pointed conductor loses its charge more rapidly than a smooth conductor. This happens because the electric field near the sharp point is very intense, which ionizes nearby air molecules and causes leakage of charge.

Corona discharge is the process of ionization of the surrounding air due to the strong electric field near a sharp point of a charged conductor. It results in a faint bluish glow, hissing sound, and continuous leakage of charge into the atmosphere.

The electric field (E) near a conductor is inversely proportional to the radius of curvature (r) of its surface. Since a sharp point has a very small radius of curvature, the electric field near it becomes very strong.

A natural example of corona discharge is St. Elmo’s fire, where a bluish glow appears on the tips of ship masts or church steeples during thunderstorms due to strong electric fields ionizing the air.

Lightning conductor– A pointed rod on top of tall buildings leaks charge gradually, preventing sudden lightning strikes.
Electrostatic precipitator – Used in industries to remove dust and smoke particles from exhaust gases using ionization by corona discharge.

Factors include:
Sharpness of the point (sharper points give stronger fields).
Applied potential difference.
Medium surrounding the conductor (air, helium, etc.).
Atmospheric conditions like humidity and pressure.

Sharp objects discharge faster because the strong electric field at their tips ionizes surrounding air molecules, leading to continuous escape of charges, while smooth objects with larger curvature have weaker fields and discharge slowly.
